| Quantity: | |
|---|---|
Product Standard:
GB/T31028-2014《disabled/incapacitated passenger boarding vehicles》
JG5099-1988《Aerial work machinery for safety rules》
GB7258-2004《Technical specification for safe operation of motor vehicle》
IATA AHM910《Basic Requirement for Airport Ground Equipment》
IATA AHM 913《Basic Safety Requirement for Airport Ground Equipment》
IATA AHM 915 《Standard control device》
IATA AHM979《Function specification of disabled/incapacitated passenger boarding vehicles》
Serial No. | Name |
| Quantity |
|
1 | Elements for oil absorbing filters | ZX-160×100 | 1 | Hydraulic position |
2 | Elements for oil return filters | GX-100×20 | 1 | In the front of the solenoid valve enclosure |
3 | Air filter | EF4-50 | 1 | On the top of hydraulic oil tank |
4 | Bonded washer | d18 | 18 | Hydraulic valve fitting |
5 | Bonded washer | d22 | 4 | Hydraulic valve fitting |
6 | Bonded washer | d14 | 1 | Hydraulic valve fitting |
7 | Pressure meter | YN-60 0～25Mpa | 1 | Inside the solenoid valve enclosure |
8 | O-ring | d16×2.4 | 10 | Pipe junction |
9 | O-ring | d14×2.4 | 10 | Pipe junction |
10 | O-ring | d24×2.4 | 10 | Pipe junction |
11 | O-ring | D55×4 | 3 | Pressure oil filter, oil pump |
12 | O-ring | D60×3.5 | 1 | Oil pump |
13 | O-ring | 2-357 139.07×5.33 | 2×2 | Lift cylinder |
14 | O-ring | P110 109.6×5.7 | 2×2 | Lift cylinder |
15 | O-ring | 2-360148.59×5.33 | 2×2 | Lift cylinder |
16 | Dust ring | SJM03-140 d140 | 1×2 | Lift cylinder |
17 | Retainer ring | 8-357 140.41×4.65 | 4×2 | Lift cylinder |
18 | Dust ring | SJM03-140.41×4.65 | 1×4 | Arm-brace oil cylinder |
19 | Sealing ring for holes | ZW008500260 85×65×22.4 | 1×4 | Lift cylinder |
20 | Sealing ring for axles | B34555P5008 45×55×7.5 | 1×4 | Lift cylinder |
21 | O-ring | 2-216 28.17×3.53 | 1×4 | Lift cylinder |
22 | O-ring | 2-327 43.82×5.33 | 2×4 | Lift cylinder |
23 | O-ring | 2-337 75.57×5.33 | 2×4 | Lift cylinder |
24 | Dust ring | SJM03-45d45 | 1 | Oil cylinder on the left and right movable platforms |
25 | Sealing ring for holes | B74030P5008 40×30×7.5 | 2 | Oil cylinder on the left and right movable platforms |
26 | Sealing ring for axles | B3 3003 P5008 30×38×5.7 | 2 | Oil cylinder on the left and right movable platforms |
27 | O-ring | 2-219 32.92×3.53 | 3 | Oil cylinder on the left and right movable platforms |
28 | O-ring | 5-615 11.92×2.62 | 1 | Oil cylinder on the left and right movable platforms |
29 | Dust ring | SJM03-22 d22 | 1 | Oil cylinder on the front and rear extension platforms |
30 | Sealing ring for holes | B74030 P5008 40×30×7.3 | Oil cylinder on the front and rear extension platforms | |
31 | Sealing ring for axles | 2-219 32.92×3.53 | 1 | Oil cylinder on the front and rear extension platforms |
32 | O-ring | 2-212 21.82×3.53 | 3 | Oil cylinder on the front and rear extension platforms |
33 | O-ring | 5-615 11.92×2.62 | 2 | Oil cylinder on the front and rear extension platforms |
34 | O-ring | 5-615 11.92×2.62 | 1 | Oil cylinder on the front and rear extension platforms |
