OPERATING INSTRUCTIONS
Content
Ⅰ. Products introduction
Ⅱ. Technical performance parameter
Ⅲ. Structure summarization
Ⅳ. Maintenance of vehicle
Ⅴ. Trouble shooting
Attached list
Table 1 Accessories attaching vehicle
Table 2Table for height connection between elevator platform and
various types of plan hatches
Drawing 1 Hydraulic pressure schematic diagram
Drawing 2 Electric schematic diagram
Ⅰ. Products introduction
The designed height off ground for WTJ5040JKT mobile passenger stair is from 2400mm to 4400mm, which could be slightly adjusted for height tolerance between passengers stair and hatch, height of stair platform could reach 5800mm after slight adjustment, this type of passengers stair could be applied for A310, A320, A330, A340, B737, B747, B757, B767, B777.
Standard:
1. MH/T6029-2014 Special vehicles--Engineering approval evaluation program
2. J IATA AHM—920
3. IATA AHM—923
4. GB/T 23422-2009 < Function requirement of propelled passenger steps>
5. CCAR-331SB-R1
6. CCAR-140
Ⅱ. Major technical performance parameter
Chassis type: ISUZU QL1070A1KAY
Engine type: 4KH1-TCG40
Rated power (KW/r/min): 96/3400
Overall dimension (length×width×height) mm 8180×2100×3380
Wheelbase (mm) 3360
Minimal curve radius (m) ≤7.00m
Allowed maximum running speed (km/h) 80
(lifting platform close to plane) ≤3
Hundred kilometer oil exhaustion (L/100km) 8
Whole vehicle and whole spare parts quality (kg) 4900kg
Maximum load-bearing (person) 50
Ladder body inclination 31.5°～38.5°
Shrinking quantity of shrinking platform (mm) 300
Hydraulic system pressure (Mpa) 10
Hydraulic tank volume (L) 100
Hydraulic oil type: 10# hydraulic oil
Fuel tank capacity (L) 100
Tyre specification 7.00—16
Voltage (V) 12
