Electric Airport Shutter Bus

Electric Airport Shutter Bus has low power consumption, low operation & maintenance cost, high safety, high stability and high comfort ability of driver & passenger experience depending on self-developed electronic control system & smooth cooperating with the industry well-known suppliers, such as CATL, DANA, SONGZ, etc.

Safety features:

● Automatic fire extinguishing system for each battery package

● Emergency steering pump

● Safety interlock to prevent moving forward/backward if any passenger door is not fully closed

● Emergency interlock release button: override the safety interlock in emergency to move the bus to proper place

● Anti-pinch function with each passenger door

● Emergency switch for each passenger door

● Integrated emergency parking brake release system

● Reversing buzzer

● Roof hatch with ventilator fan

● Safety hammer for each door

● Manual fire extinguishers in both driver-cab & passenger-cab

● 02 towing hooks in front & rear

● External air re-filling point

● 02 Amber beacons on the roof

● Necessary warning signs (In English)
Availability:
Quantity:
  • Storm PD6300E

  • Storm Aviation GSE

Manufacturer

Storm Aviation GSE

Model

Storm PD6300E

Year

2025

Condition

New

Stock Number

Storm PD6300E

Overall dimension mm

14,000*3,000*3,195

Wheelbase mm

7,200

Internal headroom

2,420mm high

Door opening width

1,250mm (extra wide design for 02

passengers to pass smoothly)

Door entrance height

2,055mm

Entrance step height

280~350mm, adjustable

Overhang front

2,950mm

Overhang rear

3,850mm

Min. turning radius

≤13,500 mm

Curb weight

13,500Kg

G.V.W.

23,000Kg

Passenger capacity

123 passengers including 08

passenger seats (if 05 persons/m2)

Bus body & chassis

Low bed type chassis   obe fully made of high strength steel, using

Cathode Electric

Coating technology for the body & chassis

with excellent anti-

corrosion performance during life-long time

Floor

Flat floor without

stepsoNon-slip surface with door area marked in yellow color

Battery type

Lithium-ion Ferrous Phosphate (LFP)

battery

Battery capacity

281kwh

Driving range

270~290Km (A/C off) o90~210Km (A/C on)

IP grade

IP68

Rated power

≥130kw

A/C system Model

2*ESD-VIA-T

A/C system Type

Top-mounted

independent A/C

system for both driver- cab & pax-cab with

max. cooling capacity 63,640Kcal/h

Refrigeration

R407C

Front axle

BEIBEN 10-ton

steering-drive axle

Rear axle

YUEK 13-ton

supporting axle

Tires

Front: 385/65R22.5, single tire per sideo Rear: 275/70R22.5,  twins tire per side

About driving

Left-hand drive
