Technical Specifications.

1 Standard Dimensions

1.1 Overall length   9.8 M

1.2 Overall height, lowered 2.7 M

1.3 Overall width   2.65 M

1.4 Platform length  6.33 M

1.5 Extension platform length 2.5 M

1.6 Platform width   2.45 M

1.7 Minimum platform height 1.95 M

1.8 Maximum platform height 10 M

1.9 Platform capacity  1,500 kg

1.10 Extension platform capacity 600 kg

1.11 Shipping weight  15,500 kg

2 Vehicle - ISUZU FVR

2.1 Engine: 6HK1-TCL, 7790cc, 177KW, Max.760Nm.

Water-cooled four-stroke diesel electrojet engine, EU V

2.2 Wheelbase: 5.5 M

2.3 GVWR: 18,000 kg

2.4 Allison Automatic transmission

2.5 Heavy duty alternator and battery

2.6 Power steering

2.7 Power brakes

3.0 Hydraulic System

3.1 PTO

3.2 Solenoid operated directional control valve

3.3 Auxiliary hand pump for emergency retraction of stabilizers

3.4 Emergency lowering of platform

4.0 Electrical System

4.1 24 volt chassis

4.2 Engine hour meter

4.3 Four platform floodlights

4.4 Amber flashing beacon

5.0  General Construction

5.1 Double scissors, steel tubing

5.2 Aluminum tread plate flooring

5.3 Grease fittings provided at all pivot points

5.4 Rubber bumpers all around

5.5 Protected with epoxy-based primer and polyurethane paint

6.0 Safety Features

6.1 Lock valve mounted on each hydraulic cylinder

6.2 Warning lights in cab to indicate stabilizer and platform position

6.3 Four hydraulically operated stabilizers

6.4 Hydraulic pressure switch prevents platform from raising unless stabilizers are down

6.5 Mechanical valve does not allow stabilizers to retract unless platform is fully lowered

7.0  Options

7.1 Alternative chassis, engine and transmission

7.2 Ziebart rust proofing

7.3 Additional paint colors

7.4 Custom placards/decals/logos

7.5 Power pack for emergency operation

7.6 Grill guard and protective bumper

7.7 Morse shifter

7.8 Backup floodlights, available only with Morse Shifter

7.9 Front and/or rear tow hooks
