Storm PD320
Model Performance | Storm PD320 | |||
Nominal cooling capacity | TR | 90 | ||
PCA hose connector | No. | 2 | ||
Air volume | Rated (cooling) | m3/h | 9500 | |
Range | m3/h | 0～10500 | ||
Static air pressure | Rated | Pa | 5500 | |
Range | Pa | 0～7350 | ||
Noise level | dB | <85 | ||
Air supply temp. range(cooling) | (℃) | -3～4 | ||
Cooling control | Multi-step regulation | |||
Power source | AC 400V 3N～50Hz | |||
Compressor | Type | Hermetically scroll type | ||
Blower | Type | Centrifugal | ||
Condenser fan | Type | Axial | ||
Refrigerant | Type | R410a | ||
Controlling form | Expansion valve | |||
Evaporator | Type | Cu-Al coil | ||
Condenser | Type | Microchannel | ||
Filter | Type | Primary aluminum filter | ||
Dimensions | Length | mm | 5300 | |
Width | mm | 2260 | ||
Height | mm | 1680 | ||
Operation Weight | kg | 4500 | ||
